Overview

Mounting version -Wall Mounted

860 CFM centrifugal blower

Three-speed mechanical, soft-touch push button control panel

Two LED lights

Aluminum multi-layers micro-cell dishwasher-friendly grease filter(s)

Machine crafted stainless steel (brushed finish)

6" round duct vent exhaust and back draft damper

Convertible to duct-free operation (requires optional charcoal filter)

Telescopic flue accommodates 8ft to 9ft ceilings (optional flue extension available for up to 10ft ceiling)

Tempered Glass Canopy

For residential use only, one-year limited factory warranty

Specifications:

BodyStainless Steel / Tempered Glass

Power Rating

120V / 60Hz (USA & Canada standard)

General Input230 W (160W + 2x35W)

Motor Input Power160 W

Motor Revolution800 RPM (±10%) to 1300 RPM (±10%)

Levels Of Speed3 Levels

Maximum Airflow860 CFM

Air Pressure150 Pa (200 Pa Maximum)

Approximately 35 / 0.7 to 67 / 6.5 (Lowest to highest Speed)

Motor TypeSingle Chamber Ultra Quiet

Fan TypeCentrifugal

Control TypeSoft-Touch Push Button

Filtration TypeAluminum Filter

IlluminationLED Lights

Venting Size6 inch Round

Interference ProtectionRadio Frequency Interference Protected
